Did you ever ask yourself, can I combine solar panels of different sizes in my solar array? It is a frequently asked question for people who would like either to scale up their existing facilities or upgrade an existing solar power system. The most crucial aspect of the integration of different sizes of solar panels is understanding how to prevail over the challenges.
You can connect multiple solar panel sizes when wiring an inverter, but they need to observe some few conditions to avoid danger or damage to the equipment.
Now, let’s move to the detail of solar panel compatibility, wiring mechanism, and the technology that are essential for a perfect combination of various solar forms and achieve the maximum of the potential of the diversity of your solar installation.
When wiring to an inverter, one may need to mix the 2 different sizes of solar panels hence the need to know how compatible they are. Now let us look at how these components fit into the whole, interfaces, and what parameters you have to mind to make them integrated cohesively.
Solar panels are different in terms of sizes, watts per panel and voltage. When modules of different sizes and characteristics are joined to a single inverter, configurations of the connection must take into consideration variations in measurements in order not to compromise performance or cause harm. Key factors include:
One has to understand that the electrical output produced by a solar panel is not standardized and that the differences in the size of the panel and the technology use results in differences in volts and amperes that the panel produces. For such panels, these discrepancies are especially important, because when panels are connected in series, they behave in a way referred to as mismatch.
Mismatch arises when panels with dissimilar electrical properties are joined, which can cause losses of power and stress both panel and system.
It is critical to avoid these problems by implementing an inverter with a higher number of MPPT Channels that will control the output from various strings of panels separately.
That is why the way that the solar panels are placed has importance in the efficiency of the panels. Thus, panels that are oriented in different manner or subject to different degree of shading during the day will produce power with different rate and at different time.
This makes it possible to have some panels shaded or poorly oriented to become the system’s bottleneck since the performance of other well-aligned panels in the some string will be restricted.
It is in these factors that the use of strategic planning and microinverters or optimizers can resolve these issues since each of the panel works on its own, making it possible to overcome the issue of shading and orientation issues.
To solve these challenges efficiently, a precise knowledge of the isolated panel requirement and knowledge of the integrated system layout is mandatory for panelized buildings.
Inverters change DC electricity from that generated by the solar panels into AC electricity. The efficiency of this process depends significantly on the compatibility between the inverter and the solar panel configuration:
Every inverter has planned limit of the voltage and current it is capable of handling. If these limits are exceeded because of connected solar panels that generates more power at certain conditions then expected, then the inverter has the capability to turn off to avoid being damaged or, even worse, fail permanently.
The maximum power point of the solar panel array should therefore not be exceeded because this will interfere with the input capabilities of the inverter. This comprises factors such as the productivity rates in normal and optimum conditions, depending on factors such as irradiation density and temperature.
The overall power rating of the inverter itself must also fit the solar panels total wattage of the panels. An under sized inverter relative to the solar array can limit the system and restrict full power output and system efficiency. On the other hand, an inverter with a power rating much higher than that of the panel may simply be uneconomical.
It is ideal that the power of inverter is nearly the same with that of the greatest power output of the solar panels, however, with some allowance for expansion of the system or slight overproduction under the best conditions.
Integrating solar panels of different sizes poses strategic challenges more issues cut across both wiring and selecting or using right technology to address different output levels.
Therefore, any time that one is looking at connecting the various sizes of the solar panels it is important to understand the difference between the series and parallel connection since each has its own advantages and disadvantage.
Series Wiring
In it, an end of the positive pole of one panel is connected to the negative pole of the other, with the total of the voltages of each panel being added, although the current remains the same as in the individual panel. This setup is best for getting high voltage output and is very useful when working with inverters that need high voltage to perform nicely.
At the same time, if the panels of different size and power output are connected in series the current capacity of the panel with the minimal rating would set the current of the string. This mismatch can cause some of the higher capacity panels to be used less than others [6], creating inefficiency in the system and potentially damaging the panels over time because they operate in conditions that are different from their design specifications.
Parallel Wiring
In contrast, Parallel Wiring conducts the positive terminal of each panel and the negative terminal of each panel such that it keeps up the voltage at the level of one panel but adds the currents of each panel. This is more appropriate for mixed size panels since it enables one panel to work to its optimum without compensating for other panels.
However, the total current output rises and it’s crucial that inverter maximum current is not exceeded in calculations. This calls for planning to avoid flowing sum current that may overwhelm inverter since this may cause shutdown or destruction of inverter.
Evaluating therefore the different wiring schemes it is crucial to consider the characteristics of both the solar panel and the inverter and the conditions of the environment and space available within the solar installation site.
The use of MPPT (Maximum Power Point Tracking) controllers is most advantageous where smaller and larger sizes of solar panels are combined. MPPT technology is aimed at tracking, within specific intervals, the maximum power point of each panel and charging the battery with optimal current in relation to the electrical load in the panel during the day and in different lighting conditions and temperature.
This capability becomes very important during instance where you have connected circuits with different electrical characteristics since the PV system must operate at optimum for each panel irrespective of other circuits. The consequence is enhanced energy acquisition and system effectiveness; therefore, makes MPPT controllers a worthy investment for gaining optimum revenue from various PV modules.
There are, however, several important factors that one needs to address when a solar power system comprises of solar panels of different sizes; factors that will determine the effectiveness of the machine and the durability of the devices.
1. Compatibility Check
They also stress the importance of checking the electrical parameters of each of the panels with regard to the voltage, current and power in relation to the capabilities of the inverter before installation.
This check also minimizes the possibilities of the inverter loading and equipment breakdown which are very dangerous. The compatibility of the electrical characteristics is also a factor because the system must efficiently operate under different environmental conditions.
2. Monitoring and Balancing
Saliently, a proper monitoring plan is central to systems that integrate panels of various dimensions. The daily monitoring of the panel enables constant control of each of them and reveal the irregularities or slowness in time.
This data is important in correcting system imbalances, increasing output, and extending the durability of the system components. They can also help determine changes or repair work that needs to be done to make sure all parts of the panels are adding to the efficiency of the system.
3. Professional Advice
It is advisable to consult a solar energy specialist particularly when installing a system with panels of different characteristics. A professional would be capable of providing information on the right setup to provide and the most appropriate equipment for use in a certain situation.
The technical experts can also assist in development of a system that would now cater for the current energy needs, but at the same time is expandable to accommodate the energy needs of the future expansion. This makes them well-placed to handle various issues which arise when combining dissimilar solar panel sizes such as, during acquisition, installation, repair, or even monitoring.
Installing one size solar panel when wiring an inverter then the other is not impossible though it needs to be done with some measure of strategy and planning. Another factor is the electrical characteristics of your panels and also your inverter should be compatible with the panels you are using. Moreover, further improvements by integrating another efficient technology like the MPPT in the system are achievable. Solar installation professionals are encouraged for those who would wish to add or make adjustments to their solar installations so that the new addition, or the modification of the existing solar system will be effective and safe.
