The following points discuss the vital issues involved in pairing the solar panels to the inverters; the consequences of overloading; correct sizing of the inverters; and efficient ways to manage additional panels including the ways of upgrading the inverters or substituting them with microinverters to maximize the solar energy systems.
A number of years ago, one of our clients, Mr. Thompson was keen to cut back his expenses on power even more so he set up additional solar panels to the facility. But instead he asked us what was to be done he connected these two to his old inveter which was not even able to cope with the load. Two weeks later he asked us to come because his inverter had burnt out and was no longer functioning. This kind of incident brought awareness to the safe method of connecting solar panels to the inverter and how it is done efficiently. How many panels may an inverter tolerate? Is it possible to get an excessive number of solar panels for an inverter?
In this case it is unwise to connect more solar panels to an inverter than it is capable of handling. However if the total power output of the solar panels equals or is below the maximum allowable input of the inverter then it is both safe and efficient. The following are some of the reasons that are as a result of overloading the inverter; This include efficiency losses, damage to the inverter and also a hazardous prospect of overheating. Correct system design, whereby the solar panel is matched with the right inverter is an incredibly important step that is necessary to ensure safe and efficient solar energy system.
Since choosing an inverter is closely connected to the choice of solar panels, there are several topics which are to be studied in detail. In the subsequent sections, now will be explained in more detail that you can make decisions about your solar energy system.
It is easier to have a clear understanding of inverter capacity.
As pertaining to this topic let us first perceive the dangers of overloading an inverter.
Tips on how to size correctly your solar panel for the inverters
Possible ways of handling extra solar panels.
The capacity of an inverter basically defines the ability of the inverter to manage current from the solar panels, expressed in watts (W) or kilowatts (kW). This rating not only tells us what is the maximum amount of power the inverter is capable of handling, but also tells us what it is capable of doing. Inverters are manufactured to work within a particular power range in order to maintain energy conversion from DC to AC as effective and safe as possible.
An important element observable in most contemporary inverters is the Maximum Power Point Tracking (MPPT). MPPT enables the solar inverter to vary voltage and current from the PV panel to optimize power production depending on the level of Sunlight input at different periods in the day. Basically, it sees that the solar panels are always at their maximum output power.
However, issues may come up whenever the power produced by the solar panels is more than what the rated capacity of the inverter allow. In such cases, although MPPT becomes advantageous, the operation efficiency of the inverter may be compromised. In cases where the inverter is overloaded, the performance as well as the efficiency drop and that usually shuts down to avoid getting damaged. This has a knock on affect on the efficiency of the solar system and also causes the inverter to degrade faster because of the heat stress and operations.
Designing a system where an inverter handles too many solar panels is very dangerous as it affects the efficiency and is a compliance issue.
Reduced Efficiency and Lifespan: The very process of integration of more panels than the inverter can support normally results to “clipping” during say, the time of the day when PV production is at its peak. Clipping is when the inverter decideds to limit the energy output to what it can handle no matter how much power is being generated by the panels. By applying this clipping, power loss is incurred with added stress on the inverter converting the high voltage in the system thus reducing the overall lifespan of the inverter due to heat generated and strain put on the component part of the inverter.
Safety Concerns: Operating at a level of capacity above the inverter rating raises the likelihood of thermal stress on the inverter and results in diminished efficiency and hazardous conditions. Excessive temperatures can affect the components inside the inverter and instance, excessive heat generates fire risks to the entire system and property and safely.
Warranty and Compliance Issues: When you add more panels to your system than your inverter can handle, this will also nullify your manufacturer’s warranty just in case of any default. Moreover, you may violate some typical electrical standards or certain state requirements, which results in fines, legal actions, or issues with insurance. It is hitherto valuable to adhere to the guidelines so as to maintain a warranty agreement and to act within the letter of the law.
When selecting an inverter it is recommended that you calculate the wattage of all the various solar panels that you intend to connect and check it with the maximum wattage allowance of the inverter. For safety, the inverter should be operated at less than its rated power to cover the fluctuations in sun intensity and efficiency of the panels themselves due to some reasons including cloud cover or change in the angle of incoming sun rays.
There should be a provision of having between 10-25% additional capacity below the actual inverter capacity to help prevent a load that is beyond its limit. This buffer assist you to avoid clipping during the time when the solar production is at its peak hence making your solar system to be more efficient and lasting longer.
If you are adding new solar panels to your system and you find that you have more panels than you have inverter capacity you need to address managing those extra panels. Here are some things to think about:
4.1 Upgrade Your Inverter
The first and most common method is to try replacing your existing inverter with a more powerful one. This is particularly important when the overall productivity of the solar panel is much higher than the current inverter system.
When you decide to use a better inverter, you are confident that all the power produced is changed without straining the system. Consider your future expansion scheme at the time of selecting a new inverter to purchase. Buying an inverter with additional capacity than out you are currently putting can be quite useful because the client does not need to sell an inverter again in the near future.
4.2 Add Another Inverter
If the first one cannot be upgraded or if your solar panels are installed in different directions or sections of the property, then the right thing to do is to install another one. This is particularly beneficial for big homes or places where are installing solar panels as some of them are installed in different directions and therefore exposed to varying amounts of sunlight during the day.
Thus, you can maintain two different inverter system arrays in separate Strings, direction and or location is a wise move since the overall efficiency of energy conversion will be increased thus reducing on mismatch or shading losses.
4.3 Use Microinverters
People now opt for microinverters as a superior and commonly used solution. In contrast to regular string inverters a single device handles many panels microinverters put one unit directly on each panel. Each solar panel functions independently with its own power conversion device through this system.
Your solar power plant functions better with microinverters that separate panel performance from each other. The system grows better when you add panels as specific microinverters match each panel's capacity rather than a single central unit.
Your solar system setup determines which transformer choice works best to meet your power needs. Getting a new inverter early lets you avoid costs when you add solar panels later and also gives you more power. You need additional inverters or microinverters when your panels generate different levels of power because they align better with varying light exposure.
When you choose microinverters you can monitor each solar panel independently which makes it simpler to find issues before they become serious. The system's detailed monitoring helps detect issues with each solar panel so treatments can start sooner and with less effort.
Running oversize solar panels from your grid needs to stop since it generates waste besides risking system failure and putting safety at risk.
When you select the ideal inverter size or employ multiple inverters your solar setup will operate optimally while ensuring safety which ensures top usage of your investment and effective renewable energy generation.
