Solar energy is fast becoming popular as a source of renewable energy, probably among the most efficient means of energy production. But, as for the concept of comprehending them, the process may get a little scientific. If one is a homeowner, a solar distributor or a technical professional planning to make an investment in a photovoltaic product it is crucial to understand some of the fundamental characteristics of a Solar Panel. As this article shall look at these critical indicators, they provide an understanding of the efficiency of a solar panel system.
Other important characteristics of a solar panel include short circuit current (ISC), open circuit voltage (VOC), peak power (PM), current and voltage at maximum power (Imp and Vmp), efficiency, fill factor (FF). These parameters aid in assessing the one given sun to electricity conversion effectiveness of a given solar panel.
It will be useful to discuss each of the parameters described above in more detail to appreciate them for the purpose of comparing the efficiency of solar panels.
The power rating of a solar panel, expressed in watts (W) define the maximum amount of power which the panel is capable of producing given that they are tested under STC. Standard test condition for testing PV modules presume the solar irradiance at 1000 KW/m2 while the module temperature and air mass is at 25o C and 1.5 respectively.
For instance, if a panel has power rating of 300W it implies that power in question can generate 300 watts of electricity assuming conditions of optimum power transfer. The power rating is one of the most important parameters because it defines the capacity of a solar panel to produce energy in the long term.
These are also associated with higher watts, meaning that the power density per area will be greater – in other words, more efficient. However, the wattage of the required panel depends on the client’s energy requirements and the room available for panel construction.
The measure of the effectiveness of a solar panel is computed by the ratio of electrical generated to the received sun energy. It is referred to as a percent. Improved efficiency simply suggests that the panel can now push more sunlight into electricity that can be used. This must be relevant more so when space is a limiting factor and you want to harness as much power as possible.
For instance, should a solar panel possess 20% efficiency then that informs consumers that the solar panel is capable of converting 20% of the received light into electrical energy. Today solar panel efficiency is between 15 and 25 percent or higher in some cases. Currently, the most efficient form of the panels is made using monocrystalline silicon although polycrystalline and thin film may be cheaper versions of the same product.
Efficiency is influenced by several factors, including:
Materials used: Standalone monocrystalline panels are normally more effective in their energy conversion capability than polycrystalline solar panels.
Cell structure: Technologies include Passivated Emitter and Rear Cell (PERC) enable improved efficiency of the cells.
Temperature performance: Since heat degrades some of the panels’ components, it is relatively true that panels that can handle heat with fairly high performance will likely perform better where it is hot.
The number of maximum volts produced by the solar panel in case there is no current flow is referred to as Open-circuit voltage (VOC). That is to say, it is the voltage at a point where the terminals of the panel are open circuited. VOC is expressed in volts (V) and varies with the solar cells material and configuration.
VOC is a very crucial parameter because it defines the maximum voltage available from a solar panel. Since open circuit voltage is directly proportional to items such as temperature, then high temperatures are likely to lower VOC.
VOC means the open circuit voltage of a solar panel that showing how much the solar panel is capable to generate electricity. Higher VOC implies that the panel can produce more power and this often results during cooler parts of the day when voltage isn’t an issue.
Short circuit current (Isc) is the maximum amount of current that a PV panel can deliver when there is no resistance in the circuit, that is when the solar panel’s terminals are shorted. Optimal isc is an essential measure for evaluating the existing practical panel’s output capacity under standard sunlight.
Isc is dependant on the amount of light intensity that falls on the panel and therefore has the tendency to change depending on time of the day or the prevailing climate. PV panels with higher Isc values are desirable in the case of systems where high current is required; e.g., low voltage systems.
The maximum power is also known as peak power measure at PM and it refers to the maximum amount of power available in a single cell solar panel in watts (W). This is the touchstone parameter for measuring the efficiency of any solar panel out there.
The peak power is found when getting the product of currents at maximum power times the volts at maximum power, Imp Vmp. PM is a good measure for evaluating the power rating capability of different sorts of solar panels as it presents power production at STC levels.
The most well-known measure of a panel’s capacity is referred to as peak power. The peak power refers to the amount of energy the panel is capable of delivering, and this is inversely proportional to its efficiency level; the higher the peak power, the better for sizing and choosing the solar system.
MPP is the point which gives the maximum power at which a solar panel is set to optimize both voltage and current. The current at such optimum power point is abbreviated as Imp while the voltage at this optimum power point is abbreviated as Vmp.
Imp: Amps, which is essentially the current that is known as the maximum power point current running through the solar panel.
Vmp: The voltage at which solar maximum power output is generated or the voltage at which the loaded solar panel is most powerful measured in volts.
Imp and Vmp show what performance a solar panel is capable of delivering under practical circumstances. Not moving the system too far from the MPP means that the panel will be generating the highest amount of power it can, which is efficiency in electric generation.
The temperature coefficient gives information on how a solar panel’s efficiency changes with the|temperature. Ideally, solar panels should turn heat at low temperatures and as the temperature increases, the efficiency decreases.
It is expressed in terms of a percentage decline in the power output for every increase in temperature about 25°C. For example a temperature coefficient of - 0.4 %/°C means the output of the panel decreases by 0.4% for every degree above 25°C.
This a critical parameter for facilities that are located in areas that have high temperatures and therefore panels will run at high temperature most of the time. A small temperature coefficient means the panel will work well in high temperatures, hence generate more energy.
The fill factor (FF) is an efficiency factor of the solar panel, FF describes the ratio of the maximum power to the product of the open circuit voltage Voc and short circuit current Isc. It is represented in percentage form and serves as a critical factor in the performance of a solar cell.
A fill factor of a solar panel above it implies that, it has better quality than the other product's solar panel. Normally, the maximum power point of the commercial solar panels varies at 0.7 – 0.8 COE (or fill factor).
The formula for the fill factor is:
what defines the main performance parameters of the solar panels fomula
Where:
Vmp is the voltage at maximum power
Imp is the current in the max power
Voc is the open circuit voltage
ISC is the short circuit current
The degradation rate means the constant depreciation of efficiency and the energy production capability of a solar panel. Every solar panel will degrade in performance over time, but the duration over which this process will occur can be slow or fast based on the type and brand in question.
In the case of most of the present day types of solar panel products, expect the degradation to be between 0.5 to 1 percent per year. This implies that after 20 years, the panel may be working up to 80% to 90% in terms of the initial efficiency.
Longevity is considered as one of the most valuable parameters in terms of low degradation rates of solar panels. The generation of panels with lower rate of degradation is desirable for projects which requires long duration, high performance and return on investment.
The warranty is also another measure that will simply show the level of confidence a manufacturer has in a given product. Solar panel warranties typically cover two aspects:
Product warranty: Protects against defects in materials and workmanship and usually for a period of 10-12 years.
Performance warranty: Pledge a certain measure of electricity production over the existence of the panel, normally up to twenty five years.
For instance, a performance warranty, might state, that the panel should produce 80% of the rating power after 25 years. These ensure better long-term value and performance of the panels and comes with staunch warranty guarantees.
It is important to comprehend the main indicators affecting the performance of solar panels to choose the proper panels for usage. These parameters provide information on the performance of a panel under certain conditions up to the time of their usage.
So if you are able to properly assess these factors, it will be easy for you to select the right solar panels in terms of energy efficiency, durability and value for money for your particular need.
