48V 280Ah All-in-one Energy Storage System

Czpowersourcing 48V 280Ah Energy Storage System

Cell Type	LiFePO4
Nominal Voltage	48V
Nominal Capacity	280Ah
Efficiency	≥96%
Cycle Life	≥6000 tims
Lead Time	20 days
Warranty	5 years

Inquiry Now

Product Description

Energy Storage System

5KWh/10KWh

All in one

Inquire now

Home Energy Storage System

Power Module Data	220V	110V
Battery Inverter
Rated Output Power	10,000W	5,000W
Max. Peak Power	15,000VA	10,000VA
Factor	1	1
Rated output voltage (Vac)	230Vac	120Vac
Frequency	50Hz	60Hz
Automatic switching cycles	<10 ms	<10 ms
THD	<3%	<3%
AC charging
Maximum AC charging power	3,150W	2,100W
AC charging current range	0~120A	0~40A
Rated input voltage	220/230 Vac	110/120 Vac
Input voltage range	90~275 Vac	90~140 Vac
AC output
Rated output power	5,000W	5,000W
Maximum output current	30A	50A
Frequency	50Hz	60Hz
Overload current	63A	55A
PV charging
Solar charging type	MPPT	MPPT
Maximum output power	5,500W	5,500W
PV charging current range	0~200A	0~200A
PV operating voltage range	120~500V	120~500V
MTTP voltage range	125~425V	125~425V
Common data
Dimension	620×445×130mm	620×445×130mm
Weight(Kg)	27kg	27kg
Battery Module
Battery Type	LiFePO4
Battery energy	13.44kWh
Rated Voltage	48V
Rated Capacity	280Ah
Battery operating voltage range	42~54.75 V
Maximum charging current	100A
Maximum discharge current	200A
Depth of discharge	80%
Tied quantities	2
Design life	≥6000
Dimension	750×470×250mm
Weight(Kg)	~105kg

Size Capacity Description

Inverter

Module

Battery

Module

H980×W750×T250mm H1450×W750×T250mm

One Bat. 13.44kWh

Two Bat. 26.88kWh

Certification

UN38.3

MSDS

EMC

Product application diagram
